HP 1660 Series User Manual

Characteristics (logic analyzer)
These characteristics are not specifications, but are included as additional information.
Full Channel Half Channel
Maximum State Clock Rate 100 MHz 100 MHz
Maximum Conventional Timing Rate 250 MHz 500 MHz
Maximum Transitional Timing Rate 125 MHz 250 MHz
Maximum Timing with Glitch Rate N/A 125 MHz
Memory Depth 4K 8K
*
Channel Count :
HP 1660A/AS 136 68
HP 1661A/AS 102 51
HP 1662A/AS 68 34
HP 1663A/AS 34 17
* For all modes except glitch.
Characteristics (oscilloscope)
The HP 1660AS Logic Analyzers also include the following characteristics:
Maximum Sample Rate 1 Gigasample per second
Number of Channels 2
Rise Time
(2)
1.4 ns
ADC 8-bit real time
Vertical Resolution 8 bits over 4 vertical divisions ( ± 0.4%)
Waveform Record Length 8000 points
Vertical (DC) Gain Accuracy
(4)
± 1.25% of full scale
Input Coupling 1 MΩ: ac and DC, 50 Ω: DC only
Input C Approximately 7 pF
General Information
Characteristics (logic analyzer)
1–5

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
