HP 1660 Series User Manual

Recommended Test Equipment (logic analyzer)
Equipment Required
Equipment Critical Specifications Recommended
Model/Part
Use
*
Pulse Generator 100 MHz, 3.5 ns pulse width,
< 600 ps rise time
HP 8131A Option 020 P,T
Digitizing Oscilloscope ≥ 6 GHz bandwidth, < 58 ps rise time HP 54121T P
Function Generator Accuracy ≤ (5)(10
− 6
) × frequency,
DC offset voltage ± 6.3 V
HP 3325B Option 002 P
Digital Multimeter 0.1 mV resolution, 0.005% accuracy HP 3458A P
BNC-Banana Cable HP 11001-60001 P
BNC Tee BNC (m)(f)(f) HP 1250-0781 P
Cable BNC (m)(m) 48 inch HP 10503A P,T
SMA Coax Cable (Qty 3) 18 GHz bandwidth HP 8120-4948 P
Adapter (Qty 4) SMA(m)-BNC(f) HP 1250-1200 P, T
Adapter SMA(f)-BNC(m) HP 1250-2015 P
Coupler (Qty 4) BNC (m)(m) HP 1250-0216 P, T
20:1 Probes (Qty 2) HP 54006A P
BNC Test Connector,
17x2 (Qty 1)
**
P
BNC Test Connector,
6x2 (Qty 4)
**
P,T
Digitizing Oscilloscope > 100 MHz Bandwidth HP 54600A T
BNC Shorting Cap HP 1250-0074 T
BNC-Banana Adapter HP 1251-2277 T
Light Power Meter United Detector 351 A
Alignment Tool 8710-1300 A
*A = Adjustment P = Performance Tests T = Troubleshooting
**Instructions for making these test connectors are in chapter 3, "Testing Performance."
General Information
Recommended Test Equipment (logic analyzer)
1–13
