HP 1660 Series User Manual

To test the bandwidth (oscilloscope)
Testing the bandwidth verifies the performance of the following specification:
• Bandwidth
This test verifies the bandwidth ( dc coupled) of the instrument from dc to 250 MHz.
Equipment Required
Equipment Critical Specifications Recommended
Model/Part
Signal Generator 1 - 250 MHz at approx 170 mV rms HP 8656B
Power Meter/Sensor 1 - 250 MHz ± 3% accuracy HP 436/8482A
Power Splitter Outputs differ by <0.15 dB HP 11667B
Cable Type N (m)(m) 24-inch HP 11500B
Adapter Type N (m) to BNC (f) HP 1250-0780
Set up the equipment
Turn on the equipment required and the logic analyzer. Let them warm up for 30
minutes if you have not already done so.
3–81

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
