HP 1660 Series User Manual

Supplemental Characteristics (logic analyzer)
ProbesProbes
Input Resistance 100 kΩ, ± 2%
Input Capacitance ~ 8 pF
Minimum Voltage Swing 500 mV, peak-to-peak
Threshold Range ± 6.0 V, adjustable in 50-mV increments
St at e Anal ysi sSt at e Anal ysi s
State/Clock Qualifiers 6
Time Tag Resolution
*
8 ns or 0.1%, whichever is greater
Maximum Time Count
Between States 34 seconds
Maximum State Tag Count
*
4.29 x 10
9
Timing AnalysisTiming Analysis
Sample Period Accuracy 0.01 % of sample period
Channel-to-Channel Skew 2 ns, typical
Time Interval Accuracy ± [sample period + channel-to-channel skew
+( 0.01%) ( time reading)]
Tr i gger i ngTr i gger i ng
Sequencer Speed 125 MHz, maximum
St at e Sequence Level s 12
Timing Sequence Levels 10
Maximum Occurrence Counter
Value 1,048,575
Pat t ern Recognizers 10
Maximum Pattern Width 136 channels in HP 1660A, 102 channels in HP 1661A,
68 channels in HP 1662A, 34 channels in HP 1663A
Range Recognizers 2
Range Width 32 bits each
Timers 2
Timer Value Range 400 ns to 500 seconds
Glitch/Edge Recognizers 2 (timing only)
Maximum Glitch/Edge Width 136 channels in HP 1660A, 102 channels in HP 1661A,
68 channels in HP 1662A, 34 channels in HP 1663A
*
Maximum state clock rate with time or state tags on is 100 MHz. When all pods are assigned to a state or timing machine,
time or state tags halve the memory depth.
General Information
Supplemental Characteristics (logic analyzer)
1–6

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
