HP 1660 Series User Manual

To test the time measurement accuracy (oscilloscope)
Testing the t ime measurement accuracy verifies the performance of the following
specification:
• Time Measurement accuracy
This test uses a precise frequency source to check the accuracy of time
measurement functions.
Equipment Required
Equipment Critical Specifications Recommended
Model/Part
Signal Generator 200 MHz, timebase accuracy 0.25 ppm HP 8656B Opt. 001
Cable BNC (m)(m) 48-inch HP 10503A
Adapter Type N (m) to BNC (f) HP 1250-0780
Set up the equipment
11 Turn on the equipment required and the logic analyzer. Let them warm up for 30
minutes if you have not already done so.
22 Set the signal generator to 181.81818 MHz (5.5 ns period) and approximately 600 mV
rms.
3–86

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
