HP 1660 Series User Manual

To test the voltage measurement accuracy (oscilloscope)
Testing the voltage measurement accuracy verifies the performance of the following
specification:
• Voltage measurement accuracy
This test verifies the DC voltage measurement accuracy of the instrument, using a
dual cursor measurement that nullifies offset error.
Equipment Required
Equipment Critical Specifications Recommended
Model/Part
DC Power Supply –14 Vdc to +14 Vdc, 0.1 mV resolution HP 6114A
Digital Multimeter Better than 0.1% accuracy HP 3458A
Cable BNC (m)(m) 48-inch HP 10503A
Adapter (cable to
power supply)
BNC (f) to Dual Banana Plug HP 1251-2277
Adapter BNC tee (m)(f)(f) HP 1250-0781
Blocking Capacitor BNC (m)(f) 0.18 µF, ± 200 V HP 10240B
BNC Shorting Cap HP 1250-0074
Set up the equipment
Turn on the equipment required and the logic analyzer. Let them warm up for 30
minutes if you have not already done so.
3–72

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
