HP 1660 Series User Manual

To adjust the CRT intensity
WARNING
Do not touch the CRT monitor sweep board. High voltages exist on the sweep board that
can cause personal injury.
Equipment Required
Equipment Critical Specification Recommended
Model/Part
Alignment Tool 1 8710-1300
Light Power Meter United Detector 351
11 Turn off the logic analyzer, then disconnect the power cord. Remove the cover.
Refer to chapter 6, "Replacing Assemblies," for instructions to remove the cover.
22 Connect the power cord, then turn on the logic analyzer.
33 Access the Display Test.
•
If you just finished adjusting the CRT monitor alignment, go to step 4.
•
To Access the Display Test , perform t he following st eps.
aa Insert the disk containing the functional performance verification tests into the disk
drive, then load the functional performance verification operating system into the
logic analyzer.
bb Enter the Sys PV tests and enter the Display Test. A grid pattern should appear.
44
Press the front panel Select key.
The display should show a full bright t est screen.
55 Turn the rear panel intensity adjustment to full bright.
66 Place the light power meter against the display at center screen.
4–8

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
