HP 1660 Series User Manual

To remove and replace the fan
11 Using previous procedures, remove the following assemblies:
•
Handle
•
Rear Feet
•
Cover
•
Disk Drive
•
Power Supply
•
Rear Panel
22 Remove the four fan screws.
33 Lift the fan away from the rear panel.
44 Lift the fan guard away from the rear panel.
55 Reverse this procedure to install the fan.
When installing the fan, verify the correct orientation of the fan. If you mount the fan
backwards, the instrument will overheat. Also, check the correct polarity of the fan cable.
To remove and replace the line filter
11 Using previous procedures, remove the following assemblies:
•
Handle
•
Rear Feet
•
Cover
•
Disk Drive
•
Power Supply
•
Rear Panel
22 Unsolder the ground wire from the lug on the rear panel.
33 Disconnect the line filter cable from the power supply.
44 Remove the two screws attaching the line filter to the rear panel.
55 Slide the line filter assembly out toward the rear.
66 Reverse this procedure to install the line filter.
Replacing Assemblies
To remove and replace the fan
6–13

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
