HP 1660 Series User Manual

Performance Test Record (oscilloscope)
Performance Test Record (oscilloscope)
Test Settings Results
Self-Tests Pass/Fail ________
DC CAL Output
AC CAL Output
5.000 Vdc ± 10 mV
0.8 Vp_p ± 10%
1.000 KHz ± 10%
Limits
4.990 Vdc
5.010 Vdc
0.72 Vp_p
0.88 Vp_p
900 Hz
1100 Hz
Measured
________
________
________
Input
Resistance
Channel 1
Channel 2
50 Ω± 0.5
Ω (49.5 to 50.5 Ω)
1MΩ± 10 KΩ (0.990 to 1.010 M
Ω)
50 Ω @ 20 mV/Div
1 MΩ @ 20 mV/Div
50 Ω @ 200 mV/Div
1 MΩ @ 200 mV/Div
50 Ω @ 1 V/Div
1 MΩ @ 1 V/Div
50 Ω @ 4 V/Div
1 MΩ @ 4 V/Div
50 Ω @ 20 mV/Div
1 MΩ @ 20 mV/Div
50 Ω @ 200 mV/Div
1 MΩ @ 200 mV/Div
50 Ω @ 1 V/Div
1 MΩ @ 1 V/Div
50 Ω @ 4 V/Div
1 MΩ @ 4 V/Div
________
________
________
________
________
________
________
________
________
________
________
________
________
________
________
________
3–101

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
