HP 1660 Series User Manual

Test the next pod
11 Using the 17-by-2 test connector and probe tip assembly, connect the data and clock
channels of the next pod to the output of the function generator until all pods have
been tested.
To unassign a pod pair and assign t he next pod pair t o be t ested, press the Config key. Select
t he pod pairs, then select assign or unassign in t he pop-up menu.
22
Start with "Test the TTL threshold" on page 3− 10, substituting the next pod to be
tested for pod 1.
Testing Performance
To test the threshold accuracy (logic analyzer)
3–16

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
