HP 1660 Series User Manual

Performance Test Record (logic analyzer)
Performance Test Record (logic analyzer)
HP 1660 Series Logic AnalyzerHP 1660 Series Logic Analyzer_______
Serial No.______________________ Work Order No.___________________
Recommended Test Interval - 2 Year/4000 hours Date___________________
Recommended next testing___________________ Temperature___________________
Test Settings Results
Self-Tests Pass/Fail ________
Threshold
Accuracy
± (100 mV + 3% of
threshold setting)
Limits Measured
Pod 1 TTL, ± 145 mV
ECL, ± 139 mV
-User, ± 280 mV
+User, ± 280 mV
0 V, ± 100 mV
TTL VL
TTL VH
ECL VL
ECL VH
-User VL
- User VH
+ User VL
+ User VH
0 V User VL
0 V User VH
+1.355 V
+1.645 V
-1.439 V
-1.161 V
-6.280 V
-5.720 V
+5.720 V
+6.280 V
-100 mV
+100 mV
________
________
________
________
________
________
________
________
________
________
Pod 2 TTL, ± 145 mV
ECL, ± 139 mV
-User, ± 280 mV
+User, ± 280 mV
0 V, ± 100 mV
TTL VL
TTL VH
ECL VL
ECL VH
-User VL
- User VH
+ User VL
+ User VH
0 V User VL
0 V User VH
+1.355 V
+1.645 V
-1.439 V
-1.161 V
-6.280 V
-5.720 V
+5.720 V
+6.280 V
-100 mV
+100 mV
________
________
________
________
________
________
________
________
________
________
Pod 3 TTL, ± 145 mV
ECL, ± 139 mV
-User, ± 280 mV
+User, ± 280 mV
0 V, ± 100 mV
TTL VL
TTL VH
ECL VL
ECL VH
-User VL
- User VH
+ User VL
+ User VH
0 V User VL
0 V User VH
+1.355 V
+1.645 V
-1.439 V
-1.161 V
-6.280 V
-5.720 V
+5.720 V
+6.280 V
-100 mV
+100 mV
________
________
________
________
________
________
________
________
________
________
3–94

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
