Connect the logic analyzer

Using the BNC-to-banana adapters, connect one end of each BNC cable to the 4-wire

resistance connections on the multimeter, and connect the free ends of the cables to the

BNC Tee. Connect the male end of the BNC tee to the channel 1 input of the oscilloscope

module.

To test the input resistance (oscilloscope)

3–70
