HP 1660 Series User Manual

To adjust the CRT monitor alignment
WARNING
Do not touch the CRT monitor sweep board. High voltages exist on the sweep board that
can cause personal injury.
Equipment Required
Equipment Critical Specification Recommended
Model/Part
Alignment Tool 1 8710-1300
1111 Turn off the logic analyzer, then disconnect the power cord. Remove the cover.
Refer to chapter 6, "Replacing Assemblies," for instructions to remove the cover.
22 Connect the power cord, then turn on the logic analyzer.
33 Insert the disk containing the functional performance verification tests into the disk
drive, then load the functional performance verification operating system into the
logic analyzer.
4–6

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
