Recommended Test Equipment (oscilloscope)
Equipment Required
Equipment Critical Specifications Recommended
Model/Part
Use*
Signal Generator Frequency: 1 - 250 MHz at approx .
170 mV RMS
Output Accuracy: ± 1 dB
1 MHz time base accuracy 0.25 ppm
HP 8656B Option 001 P
DC Power Supply Range: − 35.000 to +35.000 Vdc, ± 1 mV HP 6114A P
Digital Multimeter 0.1 mV resolution
Accuracy: better than 0.005%
Resistance measurement: better than
0.25% accuracy
HP 3458A P
Power Meter/Sensor 1 - 250 MHz ± 3% accuracy HP 436/8482A P
Power Splitter Outputs differ by <0.15 dB HP 11667B P
Blocking Capacitor BNC (m)(f), 0.18 µF, ± 200 V HP 10240B P
BNC Shorting Cap HP 1250-0074 P
Adapter BNC (f)(f) (UG-914/U) HP 1250-0080 C
Adapter BNC(f)-to-Dual Banana Plug HP 1251-2277 P
Adapter Type N(m)-to-BNC(f) HP 1250-0780 P
BNC Tee BNC (m)(f)(f) HP 1250-0781 P,C
Cable Type N(m-to-m) 24-inch HP 11500B P
Cable 50 Ω BNC (m-to-m) 48-inch HP 10503A P, C
Cable (2) 50 Ω BNC (m-to-m) 9 inch HP 10502A C
*A = Adjustment C = Calibrations P = Performance Tests T = Troubleshooting
General Information
Recommended Test Equipment (oscilloscope)
1–14
