To test the threshold accuracy (logic analyzer)
Testing the t hreshold accuracy verifies the performance of the following specification:
• Clock and data channel threshold accuracy.
These instructions include detailed steps for testing the threshold settings of pod 1.
After testing pod 1, connect and test the rest of the pods one at a time. To test the
next pod, follow the detailed steps for pod 1, substituting the next pod for pod 1 in
the instructions.
Each threshold test tells you to record the voltage reading in the performance test
record located at the end of this chapter. To check if each test passed, verify that
the voltage reading you record is within the limits listed on the performance test
record.
Equipment Required
Equipment Critical Specifications Recommended Model/Part
Digital Multimeter 0.1 mV resolution, 0.005% accuracy HP 3458A
Function Generator Accuracy ≤ (5)(10
− 6
) × frequency,
DC offset voltage ± 6.3 V
HP 3325B Option 002
BNC-Banana Cable HP 11001-60001
BNC Tee HP 1250-0781
BNC Cable HP 10503A
BNC Test Connector,
17x2
Set up the equipment
11 Turn on the equipment required and the logic analyzer. Let them warm up for
30 minutes before beginning the test.
22 Set up the function generator.
aa Set up the function generator to provide a DC offset voltage at the Main Signal output.
bb Disabl e any AC voltage to the function generator output, and enable the high voltage
output.
cc Monitor the function generator DC output voltage with the multimeter.
3–8

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
