HP 1660 Series User Manual

Contents
11 General I nfor mat ionGeneral Information
Accessories 1-2
Specifications (logic analyzer) 1-3
Specifications (oscilloscope) 1-4
Charact erist ics ( logic analyzer) 1-5
Characteristics (oscilloscope) 1-5
Supplemental Characteristics (logic analyzer) 1-6
Supplemental Characteristics (oscilloscope) 1-9
Recommended Test Equipment (Logic Analyzer) 1-13
Recommended Test Equipment (Oscilloscope) 1-14
22 Preparing for UsePrepar ing for Use
To inspect the logic analyzer 2-2
To apply power 2-3
To operate the user interface 2-3
To set the line voltage 2-3
To degauss t he display 2-4
To clean the logic analyzer 2-4
To test the logic analyzer 2-4
33 Testing PerformanceTesting Performance
To perform the self-tests 3-3
To make the test connectors (logic analyzer) 3-6
To test the threshold accuracy (logic analyzer) 3-8
Set up the equipment 3-8
Set up the logic analyzer 3-9
Connect the logic analyzer 3-9
Test the TTL threshold 3-10
Test the ECL threshold 3-12
Test the - User threshold 3-13
Test the + User threshold 3-14
Test the 0 V User threshold 3-15
Test the next pod 3-16
To test the glitch capture ( logic analyzer) 3-17
Set up the equipment 3-17
Set up the logic analyzer 3-18
Connect the logic analyzer 3-18
Test the glitch capture on the connected channels 3-20
Test the next channels 3-22
v

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
