HP 1660 Series User Manual

Specifications (oscilloscope)
The HP 1660AS Logic Analyzers also include the following specifications:
Bandwidth
(*,1)
DC to 250 MHz (real time, dc-coupled)
Time Interval Measurement Accuracy
(*,3,6)
± [( 0.005% X ∆t)+
(2 x 10
− 6
x delay setting)+150 ps]
DC Offset Accuracy
(*)
± ( 1.0% of channel offset + 2.0% of
full scale)
Volt age Measurement Accuracy
(*,5)
± [( 1.5% of full scale + offset accuracy)
+ ( 0.008 x V/div) ]
Trigger Sensitivity
(*)
DC to 50 MHz: 0.063 x full scale,
50 to 250 MHz: 0.125 x full scale
Input R (selectable)
(*)
1 MΩ: ± 1%, 50 Ω: ± 1%
* Specifications (valid within ± 10° C of auto-calibration temperature, excluding bandwidth− see note 1 for bandwidth specification.
1. Upper bandwidth reduces by 2.5 MHz for every degree C above 35° C.
2. Rise time is calculated from the formula:
t
r
=
0.35
bandwidth
3. Specification applies to the maximum sampling rate. At lower rates, the specification is:± [(0.005% x ∆t)+(2 x 10
-6
x delay setting)
+ (0.15 x sample interval)] for bandwidth limited signals (t
r
= 1.4 x sample interval). Sample interval is defined as
1
sample rate
4. Vertical gain accuracy decreases 0.08% per degree C from software calibration temperature.
5. Digitizing level = (#vertical divisions)(
1
2
)(
1
LSB
), where LSB=2
# bits in ADC
6. The Time Interval Measurement Accuracy deteriorates across multiple modules connected as one unit with each added module.
General Information
Specifications (oscilloscope)
1–4

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
