HP 1660 Series

To Next Page

To Previous Page

To calibrate the oscilloscope

Equipment Required

Equipment Critical Specification Recommended

Model/Part

Qty

Cable (2) BNC, 9-inch (equal length) HP 10502A 1

Cable BNC HP 10503A

Adapter BNC tee (m)(f)(f) HP 1250-0781 1

Adapter BNC (f)(f) (ug-914/u) HP 1250-0080

Set up the equipment

Turn on the logic analyzer. Let it warm up for 30 minutes if you have not already done so.

4–3
