HP 1660 Series User Manual

1111 Press the blue shift key, then press the Run key. If 2 - 4 acquisitions are obtained
without the "Stop Condition Satisfied" message appearing, then the test passes.
Press Stop to halt the acquisition. Record the Pass or Fail results in the performance
test record.
1212 Test the next clocks.
aa In the logic analyzer Format menu, select Master Clock.
bb Turn off and disconnect the clocks just tested.
cc Repeat steps 2 through 12 for the next clock edges listed in the table in step 4, until all
listed clock edges have been tested.
1313
Test the next setup/hold combination.
aa In the logic analyzer Format menu, select Master Clock.
bb Turn off and disconnect the clocks just tested.
cc Repeat steps 1 through 12 for the next setup/hold combination listed in step 1 on
page 3-42, until all listed setup/hold combinations have been tested.
When aligning the data and clock waveforms using the oscilloscope, align the waveforms
according to the setup time of the setup/hold combination being tested, +0.0 ps or − 100 ps.
Test the next channels
Connect the next combination of data channels and clock channels, then test them.
Start on page 3–38 "Connect the logic analyzer," connect the next combination, then
continue through the complete test.
To test the multiple-clock, multiple-edge, state acquisition (logic analyzer)
3–46

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
