HP 1660 Series User Manual

Product RegulationsProduct Regulations
Safety IEC 348
UL 1244
CSA Standard C22.2 No.231 ( Series M-89)
EMC This product meet s the requirement of the European
Communities (EC) EMC Directive 89/336/EEC.
Emissions EN55011/CSIPR 11 ( ISM, Group1,Class A equipment)
SABS RAA Act No. 24( 1990)
Immunity EN50082-1 Code
1
Notes
2
IEC 801-2 ( ESD) 4kV CD, 8kV AD 2
IEC 801-3 ( Rad.) 3V/m 1
IEC 801-4 ( EFT) 1kV
2
1
Performance Codes:
1 PASS - Normal operations, no effect.
2 PASS - Temporary degradation, self recoverable.
3 PASS - Temporary degradation, operator intervention required.
4 FAIL - Not recoverable, component damage.
2
Notes: ( None)
Supplemental Characteristics (oscilloscope)
Ver t ical ( at BNC)Ver t ical ( at BNC)
Vertical Sensitivity Range 4 mV/div to 10 V/div in 1-2-4 increments
(1:1 Probe)
DC Offset Range ( 1:1 Probe)
Vertical Sensitivity Available Offset
4 mV/div to 100 mV/div ± 2 V
>100 mV/div to 500 mV/div ± 10 V
>500 mV/div to 2.5 V/div ± 50 V
>2.5 V/div to 10 V/div ± 250 V
Probe Factors Any integer ratio from 1:1 t o 1000:1
Maximum Safe Input Voltage 1 MΩ: ± 250 V [DC + peak ac (< 10 KHz) ]
50 Ω: ± 5 VRMS
Channel-to-Channel Isolation DC to 50 MHz: 40 dB, 50 MHz to 250 MHz: 30 dB
TimebaseTimebase
Range 1 ns/div to 5 s/div
Resolution 20 ps
Delay Pre-trigger Range
Time/div Setting Available Delay
1 µs to 5 s/div -8 x (s/div)
1 ns to 500 ns/div -4 µs
Delay Post-t rigger Range
Time/div Setting Available Delay
100 ms to 5 s/div 2.5 ks
1 µs to 50 ms/div 33,500 x ( s/div)
1ns to 500 ns/div 16.7 ms
General Information
Supplemental Characteristics (oscilloscope)
1–9

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
