HP 1660 Series User Manual

Exploded ViewExploded View
Listing
A1 CPU board MP3 Fan guard MP26 RPG knob
A2 Acquisition board MP4 Rear panel MP27 Keyboard panel
A3 Keyboard MP5 Line filter MP29 Front panel spacer
A4 Switch actuator MP6 Ground bracket MP30 Keyboard spacer
A5 Monitor sweep cable MP7 Ground bracket W1 HP-IB cable
A7 Power supply MP8 Cabinet W2 Fan cable
A8 Disk drive MP11 Handle plate W3 RS-232C cable
A9 Monitor assembly MP19 Insulator W4 Disk drive cable
A10 Fan MP20 Mounting plate W5 Cable-60 conductor
A12 Oscilloscope Board *
A13 Attenuator *
H3 Locking pin MP23 Label W6 Jumper cable-orange
H4 BNC connector MP24 Label W7 Jumper cable-white
H29 Hex nut *
H30 Lock washer *
H32 Hex nut *
MP1 Intensity adjustment MP25 Elastomeric keypad W8 Power supply cable
MP2 Disk drive bracket W9 Cable - 60-conductor *
* HP 1660AS series only
Replacing Assemblies
6–3

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
