HP 1660 Series User Manual

HP 1660A Series and HP 1660AS Series
Logic Analyzers
The HP 1660A Series are 100-MHz State/500-MHz Timing Logic Analyzers.
The HP 1660AS Series include all the features of the HP 1660A Series, as well as a
2-channel, 1 GSa/s oscilloscope.
Feat uresFeat ures
Some of the main features of the HP 1660 Series Logic Analyzers are as follows:
• 128 data channels and 6 clock/data channels in the HP 1660A
• 96 data channels and 6 clock/data channels in the HP 1661A
• 64 data channels and 4 clock/data channels in the HP 1662A
• 32 data channels and 2 clock/data channels in the HP 1663A
• 3.5-inch disk drive
• HP-IB and RS-232C interface
• Variable setup/hold time
• 4 kbytes deep memory on all channels with 8 kbytes in half channel mode
• Marker measurements
• 12 levels of trigger sequencing for state and 10 levels of sequential triggering for
timing
• 100 MHz time and number-of-states tagging
• Full programmability
The HP 1660AS Series Logic Analyzers also include the following features:
• 1 GSa/s digitizing for 250 MHz bandwidth single shot oscilloscope
• 8000 samples per channel
• Automatic pulse parameters, displays time between markers, acquires until
specified time between markers is captured, performs statistical analysis on time
between markers
• Lightweight miniprobes
Servi ce St rat egyServi ce St rat egy
The service strategy for this instrument is the replacement of defective assemblies.
This service guide contains information for finding a defective assembly by testing
and servicing the HP 1660 Series.
This logic analyzer can be returned to Hewlett-Packard for all service work, including
troubleshooting. Contact your nearest Hewlett-Packard Sales Office for more details.
ii

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
