HP 1660 Series User Manual

The table includes all the HP 1660 Series. Use the pods that correspond to your logic
analyzer:
•
HP 1660A – pods 1 through 8
•
HP 1661A – pods 1 and 2, pods 3 and 4, and pods 5 and 6
•
HP 1662A – pods 1 and 2, and pods 3 and 4
•
HP 1663A – pods 1 and 2
Connect the Logic Analyzer to the Pulse Generator
Testing
Combinations
To HP 8131A
Channel 1 Output
To HP 8131A
Channel 1
Output
To HP 8131A
Channel 2 Output
To HP 8131A
Channel 2 Output
1 Pod 1
ch 0, 2, 4, 6,
J-clock
Pod 1
ch 1, 3, 5, 7
Pod 3
ch 0, 2, 4, 6,
L-clock
Pod 3
ch 1, 3, 5, 7
2 Pod 1
ch 8, 10, 12, 14,
J-clock
Pod 1
ch 9, 11, 13, 15
Pod 3
ch 8, 10, 12, 14,
L-clock
Pod 3
ch 9, 11, 13, 15
3 Pod 2
ch 0, 2, 4, 6,
K-clock
Pod 2
ch 1, 3, 5, 7
Pod 4
ch 0, 2, 4, 6,
M-clock
Pod 4
ch 1, 3, 5, 7
4 Pod 2
ch 8, 10, 12, 14,
K-clock
Pod 2
ch 9, 11, 13, 15
Pod 4
ch 8, 10, 12, 14,
M-clock
Pod 4
ch 9, 11, 13, 15
5 Pod 5
ch 0, 2, 4, 6,
N-clock (1661A only)
Pod 5
ch 1, 3, 5, 7
Pod 7
ch 0, 2, 4, 6,
N-clock (1660A only)
Pod 7
ch 1, 3, 5, 7
6 Pod 5
ch 8, 10, 12, 14,
N-clock (1661A only)
Pod 5
ch 9, 11, 13, 15
Pod 7
ch 8, 10, 12, 14,
N-clock (1660A only)
Pod 7
ch 9, 11, 13, 15
7 Pod 6
ch 0, 2, 4, 6,
P-clock (1661A only)
Pod 6
ch 1, 3, 5, 7
Pod 8
ch 0, 2, 4, 6,
P-clock (1660A only)
Pod 8
ch 1, 3, 5, 7
8 Pod 6
ch 8, 10, 12, 14,
P-clock (1661A only)
Pod 6
ch 9, 11, 13, 15
Pod 8
ch 8, 10, 12, 14,
P-clock (1660A only)
Pod 8
ch 9, 11, 13, 15
Testing Performance
To test the glitch capture (logic analyzer)
3–19

HP 1660 Series Specifications

General

Category	Logic Analyzer
Glitch Trigger	Yes
Pattern Trigger	Yes
State Analysis	Yes
Transitional Timing	Yes
Trigger Modes	Edge, Pattern, Glitch
