HP LaserJet M4345 MFP Service Manual

Fuser-delivery delay jam
If the fuser-delivery sensor (PS108) does not detect the leading edge of the media within a specific
period of time after the top-of-page sensor (PS103) detects the leading edge, the microprocessor on
the DC controller PCA determines that a fuser-delivery delay jam has occurred. The time varies
according to the length of the media.
The transport process stops and a 13.XX.YY JAM message appears on the control-panel display.
Fuser wrapping jam
If the fuser-delivery sensor (PS108) does not detect the trailing edge of the media within a specific
period of time after it detects the leading edge, the microprocessor on the DC controller PCA detects
that a fuser wrapping jam has occurred.
The transport process stops and a 13.XX.YY JAM message appears on the control-panel display.
Fuser-delivery stationary jam when feeding regular-size media
NOTE Regular-size media is defined as A4, letter, legal, B5, executive or A5.
If the fuser-delivery sensor (PS108) does not detect the trailing edge of the media within a specific
time period after it detects a fuser wrapping jam, the microprocessor on the DC controller PCA
detects that a fuser-delivery stationary jam has occurred.
The transport process stops and a 13.XX.YY JAM message appears on the control-panel display.
Fuser-delivery stationary jam when feeding custom-size media
If the fuser-delivery sensor (PS108) does not detect the trailing edge of the media within a specific
time period after it detects a fuser wrapping jam, the microprocessor on the DC controller PCA
detects that a fuser-delivery stationary jam has occurred.
NOTE The time period varies according to the length of the media. The interval is longer for
media that is 200 mm (7.9 inches) or longer.
The transport process stops and a 13.XX.YY JAM message appears on the control-panel display.
Reversing delay jam (face-down delivery only)
If the reversing-paper sensor (PS110) does not detect the leading edge of the media within a specific
time period after the fuser-delivery sensor (PS108) detects the leading edge, the microprocessor on
the DC controller PCA detects that a reversing delay jam has occurred.
The transport process stops and a 13.XX.YY JAM message appears on the control-panel display.
Reversing stationary jam (face-down delivery only)
If the reversing-paper sensor (PS110) does not detect the trailing edge of the media within a specific
time period after the fuser-delivery sensor (PS108) detects the trailing edge, the microprocessor on
the DC controller PCA detects that a reversing delay jam has occurred.
The transport process stops and a 13.XX.YY JAM message appears on the control-panel display.
152 Chapter 4 Theory of operation ENWW

HP LaserJet M4345 MFP Specifications

General

Print Technology	Laser
Functions	Print, copy, scan, fax
Print Speed	Up to 45 ppm
Print Resolution	Up to 1200 x 1200 dpi
Monthly Duty Cycle	Up to 200, 000 pages
Standard Input Capacity	600 sheets
Standard Output Capacity	250 sheets
Scanner Type	Flatbed, ADF
Maximum Scan Size	216 x 356 mm
Duplex Printing	Automatic
Memory, standard	256 MB
Memory, maximum	512 MB
Hard Disk	Optional
Print Languages	HP PCL 6, HP PCL 5e, HP Postscript Level 3 emulation
Paper Handling Input, Standard	100-sheet multipurpose tray, 500-sheet input tray
Scan Resolution, Optical	Up to 600 dpi
Scan Speed (Normal, A4)	Up to 45 ppm
Automatic Document Feeder Capacity	50 sheets
Copy Speed (Black, Normal Quality, A4)	Up to 45 cpm
Copy Resolution (Black Text)	Up to 600 x 600 dpi
Copy Reduce / Enlarge Settings	25 to 400%
Maximum Number of Copies	999
Fax Resolution	Up to 300 x 300 dpi
Fax Transmission Speed	3 sec per page
Connectivity	Ethernet
First Page Out	As fast as 8.5 sec
Display	LCD
Quick Dialing, Maximum Number	100 numbers
Operating System Compatibility	Windows, Mac, Linux
Network Ready	Standard (built-in Ethernet)
