331
[SwitchA-route-policy-apply_med_50-10] if-match ip address acl 2000
[SwitchA-route-policy-apply_med_50-10] apply cost 50
[SwitchA-route-policy-apply_med_50-10] quit
[SwitchA] route-policy apply_med_100 permit node 10
[SwitchA-route-policy-apply_med_100-10] if-match ip address acl 2000
[SwitchA-route-policy-apply_med_100-10] apply cost 100
[SwitchA-route-policy-apply_med_100-10] quit
# Apply routing policy apply_med_50 to routes outgoing to peer 3.0.2.2, and apply routing
policy apply_med_100 to routes outgoing to peer 2.0.2.2.
[SwitchA] bgp 200
[SwitchA-bgp-default] address-family ipv4 unicast
[SwitchA-bgp-default-ipv4] peer 3.0.2.2 route-policy apply_med_50 export
[SwitchA-bgp-default-ipv4] peer 2.0.2.2 route-policy apply_med_100 export
[SwitchA-bgp-default-ipv4] quit
# Enable BFD for peer 3.0.2.2.
[SwitchA-bgp-default] peer 3.0.2.2 bfd
[SwitchA-bgp-default] quit
4. Configure BGP on Switch C:
# Establish two IBGP connections to Switch A.
<SwitchC> system-view
[SwitchC] bgp 200
[SwitchC-bgp-default] peer 3.0.1.1 as-number 200
[SwitchC-bgp-default] peer 2.0.1.1 as-number 200
[SwitchC-bgp-default] address-family ipv4 unicast
[SwitchC-bgp-default-ipv4] peer 3.0.1.1 enable
[SwitchC-bgp-default-ipv4] peer 2.0.1.1 enable
[SwitchC-bgp-default-ipv4] quit
# Enable BFD for peer 3.0.1.1.
[SwitchC-bgp-default] peer 3.0.1.1 bfd
[SwitchC-bgp-default] quit
[SwitchC] quit
Verifying the configuration
# Display detailed BFD session information on Switch C.
<SwitchC> display bfd session verbose
Total Session Num: 1 Up Session Num: 1 Init Mode: Active
IPv4 Session Working Under Ctrl Mode:
Local Discr: 513 Remote Discr: 513
Source IP: 3.0.2.2 Destination IP: 3.0.1.1
Session State: Up Interface: N/A
Min Tx Inter: 500ms Act Tx Inter: 500ms
Min Rx Inter: 500ms Detect Inter: 2500ms
Rx Count: 135 Tx Count: 135
Connect Type: Indirect Running Up for: 00:00:58
Hold Time: 2457ms Auth mode: None
Detect Mode: Async Slot: 0
Protocol: BGP
Version: 1
