Huawei SmartAX MA5608T User Manual

c. Click Apply to apply the configuration.
4. Configure parameters of the H.248-based voice users.
a. In the navigation tree, choose Voice > VoIP Basic Configuration.
b. In the right pane, configure the parameters of voice user 1 as follows:
– Line Name: A0
– Associated POTS: 1 (binding port TEL1 on the ONU)
– Select Enable Line Name to enable the voice user configuration.
c. Click Apply to apply the configuration.
d. In the right pane, click New to add voice user 2, and configure the parameters of
voice user 2 as follows:
– Line Name: A1
– Associated POTS: 2 (binding port TEL2 on the ONU)
– Select Enable Line Name to enable the voice user configuration.
e. Click Apply to apply the configuration.
NOTE
l The terminal IDs A0 and A1 must be consistent with the corresponding configuration on the
MGC.
l If Associated POTS is 1, port TEL1 on the ONU is bound. If Associated POTS is 2, port TEL2
on the ONU is bound.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1112

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
