Huawei SmartAX MA5608T User Manual

Procedure
Step 1 Configure the OLT.
1. Configure a traffic profile.
Configure traffic profile 8. Set the CIR to off (unlimited), priority to 4, and priority-based
scheduling policy to local-setting (that is, queues are scheduled based on the priority
specified in the profile).
NOTE
Run the display traffic table ip command to query existing traffic profiles in the system. If the existing
traffic profiles in the system do not meet the requirements, run the traffic table ip command to add a
traffic profile.
huawei(config)#traffic table ip index 8 cir off priority 4 priority-policy
local-setting
2. Configure the VLAN and service flows.
Table 12-15 Data plan
VLAN Plan VLAN Translation Policy
Single VLAN tag
l S-VLAN ID: 1000
l MVLAN ID: 1000
l VLAN type: smart
l VLAN attribute: common
ONU: duplicates multicast packets based
on user ports and MVLANs are stripped
off downstream.
OLT: duplicates multicast packets based
on PON ports with MVLAN unchanged.
Configure the mapping between a GEM port and an Ethernet port on an ONU. If the ONU
is connected to the STB through Ethernet port 2, map the service flow of Ethernet port 2
to GEM port 13 in the ONU line profile.
huawei(config)#ont-lineprofile gpon profile-name ftto_line
huawei(config-gpon-lineprofile-1)#gem mapping 13 2 vlan 1000
huawei(config-gpon-lineprofile-1)#commit
huawei(config-gpon-lineprofile-1)#quit
Configure the multicast forwarding mode is untagged.
huawei(config)#ont-srvprofile gpon profile-name ftto_ser
huawei(config-gpon-srvprofile-1)#multicast-forward untag
huawei(config-gpon-srvprofile-1)#commit
huawei(config-gpon-srvprofile-1)#quit
Create a service VLAN and add an upstream port to it. Add upstream port 0/19/0 to VLAN
1000.
huawei(config)#vlan 1000 smart
huawei(config)#port vlan 1000 0/19 0
Create service flows. Set the service VLAN to 1000, GEM port ID to 13, and user VLAN
to 1000, and use traffic profile 8.
huawei(config)#service-port 1 vlan 1000 gpon 0/1/0 ont 1 gemport 13 multi-
service
user-vlan 1000 rx-cttr 8 tx-cttr 8
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1132

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
