– Select Enable Line Name to enable the voice user configuration.
c. Click Apply to apply the configuration.
d. In the right pane, click New to add voice user 2, and configure the parameters of
voice user 2 as follows:
– Line Name: A1
– Associated POTS: 2 (binding port TEL2 on the ONU)
– Select Enable Line Name to enable the voice user configuration.
e. Click Apply to apply the configuration.
NOTE
l The terminal IDs A0 and A1 must be consistent with the corresponding configuration on the
MGC.
l If Associated POTS is 1, port TEL1 on the ONU is bound. If Associated POTS is 2, port TEL2
on the ONU is bound.
5. (Optional) Configure a route.
Perform this operation if the IP address of the ONU and the IP address of the voice
server are in different network segments.
a. Choose Route > Default Route Configuration from the main menu.
b. Select Enable the default route and set WAN name to
1_VOIP_R_VID_300.
Figure 12-7 shows the settings.
Figure 12-7 Configuring a route
c. Click Apply to apply the configuration.
6. Save the configuration.
In the navigation tree, choose System Tools > Configuration File. In the right pane,
click Save Configuration to save the configuration.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1157
