Huawei SmartAX MA5608T User Manual

Table 12-26 Data plan
Scenario VLAN Plan VLAN Translation Policy
Bridging ONU
+router
Single VLAN tag
l VLAN ID: 300
l VLAN type: smart
l VLAN attribute:
common
l C-VLAN = S-VLAN
ONU: Provide the VoIP
service through the ONU.
Configure the service VLAN
(S-VLAN) tag in a unified
manner.
OLT: The OLT transparently
transmits S-VLAN tags (the
C-VLAN is the same as the
planned S-VLAN).
Configure the mapping between a GEM port and a VLAN. The service flow of user
VLAN 300 is mapped to GEM port 12 in the ONU line profile.
NOTE
The user VLAN is the VLAN in the packets sent from the router to the ONU, that is, the U-VLAN.
huawei(config)#ont-lineprofile gpon profile-name ftto_line
huawei(config-gpon-lineprofile-1)#gem mapping 12 2 vlan 300
huawei(config-gpon-lineprofile-1)#commit
huawei(config-gpon-lineprofile-1)#quit
Configure the VLAN of the Ethernet port on the ONU. If the ONU is connected to
the HGW through Ethernet port 1, add Ethernet port 1 to VLAN 45 in the ONU service
profile.
huawei(config)#ont-srvprofile gpon profile-name ftth
huawei(config-gpon-srvprofile-1)#port vlan eth 1 45
huawei(config-gpon-srvprofile-1)#commit
huawei(config-gpon-srvprofile-1)#quit
Create a service VLAN and add an upstream port to it. Add upstream port 0/19/0 to
VLAN 300.
huawei(config)#vlan 300 smart
huawei(config)#port vlan 300 0/19 0
Create service flows. Set the service VLAN to 300, GEM port ID to 12, and user
VLAN to 300, and use traffic profile ftto_voip.
huawei(config)#service-port vlan 300 gpon 0/1/0 ont 1 gemport 12 multi-
service
user-vlan 300 inbound traffic-table name ftto_voip outbound traffic-table
name
ftto_voip
huawei(config)#service-port vlan 300 gpon 0/1/0 ont 2 gemport 12 multi-
service
user-vlan 300 inbound traffic-table name ftto_voip outbound traffic-table
name
ftto_voip
3. Enable the ARP proxy function.
Voice media streams for different users of the same S-VLAN fail to interchange
because the service ports of the smart VLAN are isolated from each other. Therefore,
the ARP proxy function needs to be enabled on the OLT.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1164
