huawei(config)#arp proxy enable
huawei(config)#interface vlanif 300
huawei(config-if-vlanif300)#arp proxy enable
huawei(config-if-vlanif300)#quit
4. Save the data.
huawei(config)#save
l Configure the ONU on the Web page.
1. Log in to the Web configuration window.
a. Configure the IP address of the PC network adapter to be in the same network
segment as the IP address of the local maintenance Ethernet port on the ONU
(default: 192.168.100.1).
b. Open the Web browser, and enter the IP address of the local maintenance Ethernet
port of the ONU.
c. On the login window, enter the user name (default: telecomadmin) and password
(default: admintelecom) of the administrator. After the password authentication
is passed, the Web configuration interface is displayed.
2. Configure parameters of a voice WAN port.
a. In the navigation tree, choose WAN > WAN Configuration.
b. In the right pane, click New. In the dialog box that is displayed, configure
parameters of a WAN port as follows:
– WAN Connection: Enable
– Service List: VoIP (For configuring the VoIP service, VoIP or a combination
containing VoIP needs to be selected.)
– Mode: Route
– VLAN ID: 300 (The VLAN ID of the ONU must be the same as the user-side
VLAN ID configured on the OLT.)
– 802.1p: 5
– IP Acquisition Mode: DHCP
c. Click Apply to apply the configuration.
3. Configure parameters of the SIP-based voice interface.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1165
