a. In the navigation tree, choose Voice > VoIP Basic Configuration.
b. In the right pane, configure parameters of the SIP-based voice interface as follows
(other parameters use the default settings):
– Set Proxy Server Address below Primary Server to 200.200.200.200.
– Home Domain: softx3000.huawei.com
– Signaling Port: 1_VOIP_R_VID_300
– Region: China
NOTE
l The parameters of the SIP-based voice interface must be consistent with the corresponding
configuration on the softswitch.
l If dual-homing is configured, Proxy Server Address below Secondary Server must be
configured.
l If Signaling Port is empty, the parameter value is the same as Media Port. If the upper-
layer network requires isolation of media streams from signaling streams, create different
traffic streams for the media streams and signaling streams on the OLT, create different
WAN ports on the ONU, and bind the created WAN ports to Media Port and Signaling
Port. When the packet is forwarded from two WAN ports, the configured VLAN is carried
by default.
c. Click Apply to apply the configuration.
4. Configure parameters of the SIP-based voice users.
a. In the navigation tree, choose Voice > VoIP Basic Configuration.
b. In the right pane, configure parameters of voice user 1 as follows:
– Register User Name: 80001234
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1166
