Huawei SmartAX MA5608T User Manual

Item Data Plan for the F01D500
Cabinet
Data Plan for the N66 Cabinet
Battery high-
temperature
power-off
parameters
Battery high-temperature power-
off permission status: permit
Temperature for battery high-
temperature power-off: 53°C
Battery high-temperature power-off
permission status: permit
Temperature for battery high-
temperature power-off: 53°C
Environment
monitoring
parameters
Upper alarm threshold of the
temperature: 68°C
Lower alarm threshold of the
temperature: -5°C
Upper test threshold of the
humidity: 80°C
Lower test threshold of the
humidity: -20°C
Upper alarm threshold of the
temperature: 68°C
Lower alarm threshold of the
temperature: -5°C
Upper test threshold of the humidity:
80°C
Lower test threshold of the humidity:
-20°C
External
extended
digital
parameters
Digital parameter ID: 0
This digital parameter is set
according to the actual
requirements. The monitoring
digital parameter of the external fan
tray is set here to monitor the fan
tray. When the fan tray is faulty, the
host reports an alarm.
Valid level of digital parameter 0:
low level
When the low level represents the
valid level, the host does not report
an alarm in the case of low level.
Digital parameter ID: 0
This digital parameter is set according
to the actual requirements. The
monitoring digital parameter of the
external fan tray is set here to monitor
the fan tray. When the fan tray is faulty,
the host reports an alarm.
Valid level of digital parameter 0: low
level
When the low level represents the valid
level, the host does not report an alarm
in the case of low level.
Digital parameter ID: 1
This digital parameter is set
according to the actual
requirements. The monitoring
digital parameter of the external fan
tray is set here to monitor the fan
tray. When the fan tray is faulty, the
host reports an alarm.
Valid level of digital parameter 1:
low level
When the low level represents the
valid level, the host does not report
an alarm in the case of low level.
Digital parameter ID: 1
This digital parameter is set according
to the actual requirements. The
monitoring digital parameter of the
external fan tray is set here to monitor
the fan tray. When the fan tray is faulty,
the host reports an alarm.
Valid level of digital parameter 1: low
level
When the low level represents the valid
level, the host does not report an alarm
in the case of low level.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
100

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
