Data Planning
Table 12-50 Key data plan
Configuration
Item
Data
DBA profile Profile ID: 20
Profile type: Type 3
Assured bandwidth: 100 Mbit/s
Maximum bandwidth: 120 Mbit/s
Line profile Profile ID: 10
T-CONT ID: 4
GEM port ID for Layer 2 interoperation service: 12
Service profile Profile ID: 11
Ethernet and POTS port capability set: adaptive
ID of the ONU Ethernet VLAN: 300
NOTE
Ensure that the capability set of the service profile is greater than or equal to that
of the device. Otherwise, some ports fail to be configured.
Networking data For example, add two ONUs (ONU 1 and ONU 2) for carrying services
of different branches.
l ONU 1 is connected to PON port 0/3/1.
l ONU 2 is connected to PON port 0/4/1.
Procedure
Step 1 Configure GPON ONU profiles.
1. Configure a DBA profile.
huawei(config)#dba-profile add profile-id 20 type3 assure 102400 max 122880
2. Configure an ONU line profile.
a. Create GPON ONU line profile 10.
huawei(config)#ont-lineprofile gpon profile-id 10
NOTE
Create a line profile according to the data plan. The ID of the line profile to be created cannot conflict
with existing profile IDs in the system. In this example, the ID of the line profile is 10.
b. In the line profile configuration mode, bind T-CONT 4 to DBA profile 20.
huawei(config-gpon-lineprofile-10)#tcont 4 dba-profile-id 20
c. In the line profile configuration mode, bind GEM ports to T-CONTs.
Add GEM port 12 for carrying the Layer 2 interoperation service flow.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1238
