GEM port 11 is bound to T-CONT 4. During configuration, set QoS policies for each
service flow. For details on QoS data planning, see 13.2.3 Principle of QoS Data
Plan.
huawei(config-gpon-lineprofile-10)#gem add 12 eth tcont 4 cascade on
d. Configure mapping between GEM ports and ONU-side services.
Set the mapping mode to VLAN mode (the default mode). Map Layer 2 interoperation
service flow (C-VLAN 300) to GEM port 12.
huawei(config-gpon-lineprofile-10)#gem mapping 12 1 vlan 300
e. After the configuration is complete, run the commit command to make the configured
parameters take effect.
huawei(config-gpon-lineprofile-10)#commit
huawei(config-gpon-lineprofile-10)#quit
3. Configure an ONU service profile.
a. Create a GPON ONU service profile with ID 11.
huawei(config)#ont-srvprofile gpon profile-id 11
NOTE
Ensure that the ID of the service profile to be created does not exist in the system. Create a service
profile according to the planned data. Service profile 11 is used as an example.
b. Configure the Ethernet and POTS port capability set to adaptive. Then, the system
adapts the capability to the actual capability of the online ONU.
huawei(config-gpon-srvprofile-11)#ont-port eth adaptive pots adaptive
c. Add Ethernet port 1 to VLAN 300.
huawei(config-gpon-srvprofile-11)#port vlan eth 1 300
d. Run the commit command to make the configurations take effect.
huawei(config-gpon-srvprofile-11)#commit
huawei(config-gpon-srvprofile-11)#quit
4. Set the ID of the native VLAN containing Ethernet port 1 to 300.
huawei(config)#interface gpon 0/3
huawei(config-if-gpon-0/3)#ont port native-vlan 1 1 eth 1 vlan 300
huawei(config-if-gpon-0/3)#quit
huawei(config)#interface gpon 0/4
huawei(config-if-gpon-0/4)#ont port native-vlan 1 2 eth 1 vlan 300
huawei(config-if-gpon-0/4)#quit
5. (Optional) Configure an alarm profile.
l The default GPON alarm profile ID is 1. The value of each alarm threshold is 0 which
indicates that alarms are not reported.
l In this example, the default alarm profile is used and no configuration is required.
Step 2 Add ONUs to the OLT.
1. Add ONU 1 and ONU2 in offline mode.
Connect ONU 1 and ONU 2 to GPON ports 0/3/1 and 0/4/1 respectively through an optical
splitter. The serial numbers of the two ONUs are 32303131B39FD641 and
32303131B39FD642 respectively, and the management mode is OMCI. Both the ONUs
are bound to line profile 10 and service profile 11.
huawei(config)#interface gpon 0/3
huawei(config-if-gpon-0/3)#ont add 1 ontid 1 sn-auth 32303131B39FD641
omci ont-lineprofile-id 10 ont-srvprofile-id 11
huawei(config-if-gpon-0/3)#quit
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
12 FTTO Configuration(SOHO and SME)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1239
