Data Plan
Table 15-54 Data plan
Item Data
GPON cascading
board
Board: H801GPMD
Port ID: 0/3/1
Remote extended frame ID: 1
Remote extended frame authentication mode: SN
Remote extended frame SN: 48575443E6D8B541
NOTE
The OLT uses the MA5603T as an example. The configuration method is the
same for other OLTs. The only difference lies in slot IDs.
Dynamic
bandwidth
allocation (DBA)
Profile: default
Type: type4
Maximum bandwidth: 1000 Mbit/s
Line profile Profile: default
GPON encapsulation mode (GEM) port ID: 0 (fixed port in centralized
management mode)
Transmission container (T-CONT) ID: 1 (fixed T-CONT in centralized
management mode)
MA5633
management
mode
extend-frame
Procedure
l Configure the working mode of the DHCP layer 2 forwarding mode.
huawei(config)#dhcp mode layer-2
l Enable the DHCP option82 feature.
The DHCP feature does not have any mechanism for authentication or security. Thus, the
DHCP feature encounters many security problems when it is used in the network. To solve
these problems, the DHCP option82 is introduced.
huawei(config)#dhcp option82 enable
l Add a remote extended frame in offline mode.
huawei(config)#frame add 1 MA5633 extending-port 0/3/1 sn 48575443E6D8B541
NOTE
When running the frame add command to add a remote extended frame in offline mode, the OLT
automatically allocates a temporary SN for the remote extended frame. Therefore, you do not need to
specify the SN of the remote extended frame. After obtaining the SN of the remote extended frame, run
the frame bind command to add the binding relationship between the SN and the remote extended frame
to the OLT. Then the remote extended frame is added.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
15 OptiCable D-CMTS Configuration (MA5633 Working as
a Remote Extended Frame)
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1650
