Huawei SmartAX MA5608T User Manual

Data Plan
Table 17-3 provides the OLT data plan, and Table 17-4 provides the ONU data plan.
Table 17-3 Data plan for configuring intelligent collection of power consumption information
in the electrical power system over Ethernet-OLT side
Item Data
VLAN
l Uplink port: 0/19/0
l Inband management VLAN: smart VLAN 8
l Service VLAN: smart VLAN 100
Inband management IP
address
IP address: 192.168.50.20/24
GPON service board
l Port: 0/3/1
l ONU ID: 1
l ONU authentication mode: SN
l ONU SN: 48575443E6D8B541
DBA profile
l Profile name: Data
l Type: type3
l Assured bandwidth: 20 Mbit/s
l Maximum bandwidth: 50 Mbit/s
ONU line profile
l Profile ID: 10, bound to DBA profile Data
l GEM port ID: 0 (used for transmitting inband management
service stream)
l GEM port ID: 1 (used for transparently transmitting meter
data)
l T-CONT ID: 5
ONU management mode SNMP
Table 17-4 Data plan for configuring intelligent collection of power consumption information
in the electrical power system over Ethernet-ONU side
Configuration
Item
Data Remarks
Inband
management IP
address
IP address: 192.168.50.2/24 -
Traffic profile Index 6 (default) -
Service port 0/1/0 -
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 17 Electrical Service Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1808

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
