Huawei SmartAX MA5608T User Manual

Devi
ce
Item Data
Priority The 802.1p priority is used: The priority of
the site information about the electrical
power system is 1 and the priority of
GOOSE packets is 5.
Table 17-6 Data plan for configuring automatic transmission of site information in the electrical
power system over Ethernet-ONU side
Device Configurati
on Item
Data Remarks
ONU_A Inband
management
IP address
192.168.50.2/24 -
Traffic
profile
l Index 10 (used for transmitting the
power distribution site
information)
l Index 11 (used for transmitting
GOOSE packets)
-
Service port Ethernet port: 0/1/1 Port 0/1/1 is used
for services on
terminal unit A.
Uplink port GPON port
l 0/0/0: active uplink port
l 0/0/1: standby uplink port
-
Uplink
VLAN
l Smart VLAN 8 (used for inband
management VLAN)
l Smart VLAN 200 (used for
transmitting power distribution site
information)
l Smart VLAN 100 (used for
transmitting GOOSE packets)
The uplink VLAN
must be the same
as the CVLAN on
the OLT.
Priority The 802.1p priority is used: The
priority of power distribution site
information is 1 and the priority of
GOOSE packets is 5.
-
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 17 Electrical Service Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1818

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
