Table 17-5 Data plan for configuring automatic transmission of site information in the electrical
power system over Ethernet-OLT side
Devi
ce
Item Data
OLT Uplink port Ethernet port: 0/19/0
VLAN
l Inband management virtual local area
network (VLAN): smart VLAN 8
l Customer VLAN (CVLAN): smart
VLAN 200; service VLAN (SVLAN):
smart VLAN 200 (used for transmitting
the site information about the electrical
power system)
l CVLAN: smart VLAN 100; SVLAN:
smart VLAN 100 (used for transmitting
GOOSE packets)
Inband management IP address IP address: 192.168.50.20/24
GPON service board
The GPON service board can be the
H801GPBC, H802GPBD, or
H805GPBD board.
l Port:
– 0/3/1: GPON port connecting to the
active line
– 0/4/1: GPON port connecting to the
standby line
l ONU ID: 1
l ONU authentication mode: SN
l ONU SN: 48575443E6D8B541
DBA profile
l Profile name: Data
l Type: type3
l Assured bandwidth: 20 Mbit/s
l Maximum bandwidth: 50 Mbit/s
ONU line profile
l Profile ID: 10, bound to the DBA
profile named Data
l GEM port ID: 0 (used for transmitting
inband management service stream)
l GEM port ID: 1 (used for transparently
transmitting the information about the
electrical power system)
l GEM port ID: 2 (used for transparently
transmitting GOOSE packets)
l T-CONT ID: 5
ONU management mode
SNMP
