NOTE
If a port on the OLT connects to multiple ONUs of the same type and the port on the OLT is
bound to the same line profile or service profile, you can add ONUs in batches by confirming
the automatically discovered ONUs in batches. This function simplifies operations and
improves configuration efficiency. For example, in the preceding information, huawei(config-
if-gpon-0/3)#ont confirm 1 ontid 1 sn-auth 48575443E6D8B541 snmp ont-lineprofile-id
10 desc MA5621_0/3/1/1_lineprofile10 can be changed to huawei(config-if-gpon-0/3)#ont
confirm 1 all sn-auth snmp ont-lineprofile-id 10 desc MA5621_0/3/1_lineprofile10.
5. Confirm that the ONU goes online properly.
After adding the ONU, run the display ont info command to query the ONU status. Ensure
that Control flag is active, Run State is online, and Config state is normal.
huawei(config-if-gpon-0/3)#display ont info 1 1
---------------------------------------------------------------------
F/S/P :
0/3/1
ONT-ID :
1
Control flag : active //The ONU has been
activated.
Run state : online //The ONU is
online.
Config state : normal //The ONU configuration status has been
restored.
...//The follow-up terminal display is omitted.
If the ONU status is abnormal, the ONU cannot be in the up state, or the ONU does not
meet requirements, check the ONU status based on the preceding information.
l If Control flag is deactive, run the ont activate command in GPON port mode to
activate the ONU.
l If the ONU cannot be in the up state (Run state is offline), check materials and lines
because the physical line may be cut or the optical module may be damaged.
l If the ONU status is abnormal (Config state is failed), ONU capabilities cannot support
the configured ONU capability set. Then run the display ont failed-configuration
command in diagnosis mode to check failed configuration items and failure causes.
Then, rectify the fault based on site requirements.
NOTE
If an ONT supports only four queues, the values 4 through 7 of the priority-queue parameter in the
gem add command are invalid, which causes Config state to be failed.
6. Configure a management channel from the OLT to the ONU.
NOTE
A management channel needs to be configured only when the OLT remotely manages the ONU using
SNMP.
a. Configure the inband management VLAN for the OLT and set the inband management
IP address.
To log in to the ONU from the OLT and configure the ONU remotely, configure the
inband management VLAN for the OLT and the ONU and set the inband management
IP address.
Configure inband management VLAN 8 and set the inband management IP address
to 192.168.50.10/24.
huawei(config-if-gpon-0/3)#quit
huawei(config)#vlan 8 smart
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
17 Electrical Service Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1854
