service flow is used to carry IPv6 and IPv4 Internet services, and the same service VLAN
is used.
l For multicast service, the ONU is the node to make multicast duplication. The configuration
procedure is the same for IPv4 multicast and IPv6 multicase. The IPv4 multicast service
and IPv6 multicast service can be configured in the same multicast VLAN on the ONU
equipment.
Data plan on the OLT side
Item Data Memo
ONU data plan
DBA profile Profile name: fttb_dba
Profile type: type3
Assured bandwidth: 8
Mbit/s
Maximum bandwidth: 20
Mbit/s
The ONU is connected to OLT through
the GPON interface.
Line profile Profile name: fttb(c)
Profile ID: 10
T-CONT ID: 4
GEM port ID for
management service: 11
GEM port ID for Internet
access service: 12
GEM port ID for VoIP
service: 13
Network topology
data
PON port: 0/2/1
ONT ID: 1
LAG data plan
LAG Ports: 0/19/0 and 0/19/1
Working mode: LACP
static aggregation
Configure upstream ports 0/19/0 and
0/19/1 into an aggregation group. Each
member port in the aggregation group
allocates packets based on the source
MAC address.
Queue scheduling data plan
Queue scheduling Queue scheduling: strict
priority (SQ) mode
Priority mapping: mapped
into different queues based
on priorities
System default is adopted in this
example.
Management channel data plan
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 19 IPv6 Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1905
