Item Data Memo
Management VLAN
and management IP
address on the OLT
side
Management VLAN ID: 8
Management VLAN type:
smart VLAN
Inband management IP
address: 192.168.50.1/24
To configure the MDU from the OLT
by logging in to the MDU, the
management VLAN of the OLT and
that of the MDU must be the same, and
the management IP address of the OLT
and that of the MDU must be in the
same network segment.
Management VLAN
and management IP
address on the ONU
side
Management VLAN ID: 8
Management VLAN type:
smart VLAN
Inband management IP
address: 192.168.50.2/24
Service channel data plan
Internet access
service
S-VLAN ID: 100; S-VLAN
attribute: stacking
C-VLAN ID: 1000-1016
Traffic profile: 6
Plan the Internet access service in per
user per service per VLAN (PUPSPV)
mode and apply S-VLAN+C-VLAN to
differentiate users.
The 802.1p priority of the Internet
access service is 0, and rate limitation
is not required. System traffic profile 6
can be used.
For details, see 19.4.2 Data Planning.
VoIP service S-VLAN ID: 200
C-VLAN ID: 200
Traffic profile: 9
The voice over IP (VoIP) service is a
carrier-operating, closed service and
primarily adopts only S-VLAN tags,
which are transparently transmitted by
OLTs.
The 802.1p priority of the VoIP service
is 5, and rate limitation is not required.
System traffic profiles do not meet the
requirements and new traffic profile
shall be configured.
For details, see 19.4.2 Data Planning.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 19 IPv6 Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1906
