Item Data Memo
VoD service S-VLAN ID: 300
Traffic profile: 10
Plan the video on demand (VoD)
service in per user per VLAN (PUPV)
mode if possible, as the VoD service
requires only a few VLAN resources.
The VoD service is a carrier-operating,
closed service and primarily adopts
only S-VLAN tags, which are
transparently transmitted by OLTs.
The 802.1p priority of the VoD service
is 4, and rate limitation is not required.
System traffic profiles do not meet the
requirements and new traffic profile
shall be configured.
For details, see 19.4.2 Data Planning.
Multicast service
Multicast VLAN ID: 1000
Multicast cascading port:
0/2/1
IGMP version: IGMPv3
IGMP mode: IGMP proxy
Multicast IP address range:
224.1.1.10-224.1.1.100
IP address of the multicast
server: 10.10.10.10/24
Traffic profile: 10
The multicast service is a carrier-
operating, closed service and primarily
adopts only S-VLAN tags.
Take the same traffic profile with the
VoD service.
For details, see 19.4.2 Data Planning.
Security data plan
System security Anti-DOS attack: disabled
Anti-ICMP attack: disabled
Anti-IP attack: disabled
System default is adopted in this
example.
User security Anti-MAC duplicate:
disabled
Anti-IP sproofing: disabled
System default is adopted in this
example.
Service security Forward the packet with
PITP tag: enabled
Forward the packet with
DHCPv4 Option82:
enabled
Forward the packet with
DHCPv6 Option18/37:
enabled
In this example, the location
information is added to packets by the
ONU equipment and these packets are
forwarded by the OLT equipment.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
19 IPv6 Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1907
