Huawei SmartAX MA5608T User Manual

Item Data Memo
Traffic profile Profile name: ftth_voip
CIR: not limited
Priority: 5
Networking data IP address of the MGC
server: 200.200.200.200/24
Port ID of the MGC server:
2944
Bridge WAN multicast service data plan
ONT line profile Profile name: ftth
T-CONT ID: 4
GEM port ID: 13
For details, see 19.6.2 Data Plan.
ONT service profile Profile name: ftth
ONT port capability set:
adaptive
Traffic profile ID: 8
802.1p priority: 4
CIR: off (unlimited)
Priority-based scheduling
policy: local-setting
VLAN Plan SVLAN ID: 1000
VLAN type: smart
VLAN attribute: common
VLAN Translation
Policy
ONT: duplicates packets
based on user ports and
multicast VLANs
(MVLANs) are stripped off
downstream.
OLT: duplicates multicast
packets based on PON ports
with MVLAN unchanged.
Multicast service
data
Multicast protocol: IGMP
proxy
Multicast version: IGMPv2
Multicast program:
dynamic obtaining mode
Program address area:
ff15::-ff15::ffff
VOD service data plan
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 19 IPv6 Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1942

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
