Item Data Memo
ONT line profile Profile name: ftth
T-CONT ID: 4
GEM port ID: 13
For details, see 19.6.2 Data Plan.
ONT service profile Profile name: ftth
ONT port capability set:
adaptive
Traffic profile ID: 8
802.1p priority: 4
CIR: off (unlimited)
Priority-based scheduling
policy: local-setting
VLAN Plan Single VLAN tag
l SVLAN ID: 1100
l VLAN type: smart
l VLAN attribute:
common
l CVLAN: 2001
VLAN Translation
Policy
The ONT adds CVALN
tags (configured on the
iTMS) to packets: untag<-
>C.
The OLT implements
VLAN translation: C<->S.
Procedure
Step 1 Configure LAG for upstream ports.
Configure upstream ports 0/19/0 and 0/19/1 into an aggregation group. Each member port in the
aggregation group allocates packets based on the source MAC address. The working mode is
LACP static aggregation.
huawei(config)#link-aggregation 0/19 0-1 ingress workmode lacp-static
Step 2 Configure GPON ONT profiles.
1. Configure a DBA profile.
Create the same DBA profile for different types of services. Set the profile name to
ftth_dba, profile type to type3, assured bandwidth to 8 Mbit/s, and maximum bandwidth
to 20 Mbit/s.
huawei(config)#dba-profile add profile-name ftth_dba type3 assure 8192 max
20480
2. Configure an ONT line profile.
Create a GPON ONT line profile, named ftth, and bind it to the DBA profile ftth_dba.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
19 IPv6 Configuration
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1943
