Procedure
Step 1 Configure the upstream VLAN interface for the media stream and the signaling stream.
The VLAN ID is 50, the VLAN type is smart VLAN, the upstream port is 0/19/0, and the IP
address of the VLAN interface is 10.50.1.10/24.
huawei(config)#vlan 50 smart
huawei(config)#port vlan 50 0/19 0
huawei(config)#interface vlanif 50
huawei(config-if-vlanif50)#ip address 10.50.1.10 24
huawei(config-if-vlanif50)#quit
NOTE
If the packet transmitted from the upstream port is untagged, run the native-vlan command to configure
the native VLAN of the upstream port to be the same as the VLAN of the upstream port.
Step 2 Configure the media and signaling IP address pools.
The media and signaling IP addresses are 10.50.1.10/24, and the gateway IP address is 10.50.1.1.
huawei(config)#voip
huawei(config-voip)#ip address media 10.50.1.10 10.50.1.1
huawei(config-voip)#ip address signaling 10.50.1.10
huawei(config-voip)#quit
NOTE
When configuring the SIP interface attributes, ensure that the media and signaling IP addresses exist in the
corresponding address pools.
Step 3 Configure a static route to the IMS.
The IP address of the destination network segment of the static route to the IMS is 10.10.1.0/24,
and the gateway IP address is 10.50.1.1.
huawei(config)#ip route-static 10.10.1.0 255.255.0.0 10.50.1.1
Step 4 Add a SIP interface.
SIP interface 0 is added.
huawei(config)#interface sip 0
Are you sure to add the SIP interface?(y/n)[n]:y
Step 5 Configure the basic attributes of the SIP interface.
The media and signaling IP addresses of the SIP interface are 10.50.1.10/24, the signaling port
ID is 5555, the transmission protocol is UDP (default setting), the IP address 1 of the primary
proxy server is 10.10.1.1/24, the port ID of the primary proxy server is 5555, the IP address 1
of the secondary proxy server is 10.10.1.2/24, the port ID of the secondary proxy server is 5555,
the home domain name is MA5600T/MA5603T/MA5608T.com, and the profile index is 0.
huawei(config-if-sip-0)#if-sip attribute basic media-ip 10.50.1.10 signal-ip
10.50.1.10 signal-port 5555 transfer udp primary-proxy-ip1 10.10.1.1 primary-proxy-
port 5555
secondary-proxy-ip1 10.10.1.2 secondary-proxy-port 5555 home-domain MA5600T/
MA5603T/MA5608T.com sipprofile-index 0
Step 6 Configure the optional attributes of the SIP interface.
The domain name of the SIP interface is huawei.com, and the phone context is +86755.
huawei(config-if-sip-0)#if-sip attribute optional mg-domain huawei.com phone-
context +86755
Step 7 Reset the SIP interface.
huawei(config-if-sip-0)#reset
Are you sure to reset SIP interface?(y/n)[n]:y
huawei(config-if-sip-0)#quit
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
173
