huawei(config)#vdsl line-profile quickadd 3 snr 60 0 300 60 0 300
huawei(config)#vdsl channel-profile quickadd 3 path-mode ptm interleaved-delay
8 2 inp 4 2 rate
128 10000 128 10000 2048 2048
huawei(config)#vdsl line-template quickadd 3 line 3 channel1 3 100 100
2. Activate VDSL port 0/4/1, and bind the preset VDSL line template 3 and the default VDSL
alarm template (alarm template 1) to the port.
NOTE
By default, a VDSL port is in the activated state. Before binding a template to the port, you must deactivate
the port.
huawei(config)#interface vdsl 0/4
huawei(config-if-vdsl-0/4)#deactivate 1
huawei(config-if-vdsl-0/4)#activate 1 template-index 3
huawei(config-if-vdsl-0/4)#alarm-config 1 1
huawei(config-if-vdsl-0/4)#quit
3. Run the display traffic table command to query the existing traffic profiles in the system.
huawei(config)#display traffic table ip from-index 0
{ <cr>|to-index<K> }:
Command:
display traffic table ip from-index 0
---------------------------------------------------------------------------
TID CIR CBS PIR PBS Pri Copy-policy Pri-Policy
(kbps) (bytes) (kbps) (bytes)
---------------------------------------------------------------------------
0 1024 34768 2048 69536 6 - tag-pri
1 2496 81872 4992 163744 6 - tag-pri
2 512 18384 1024 36768 0 - tag-pri
3 576 20432 1152 40864 2 - tag-pri
4 64 4048 128 8096 4 - tag-pri
5 2048 67536 4096 135072 0 - tag-pri
6 off off off off 0 - tag-pri
---------------------------------------------------------------------------
Total Num : 7
According to service requirements, the user access rate is 2048 kbit/s. The query result
shows that traffic profile 5 (for inbound and outbound rate limitation) meets the
requirements.
NOTE
l If a matched traffic profile is not available in the system, run the traffic table ip command to configure
a new traffic profile.
l On the MA5600T/MA5603T/MA5608T, the user access rate can be limited by either a traffic profile
or a VDSL line profile. When both profiles are configured, the smaller one of the two rates configured
in the profiles is adopted as the user bandwidth. In this example, the traffic profile is used to limit the
user access rate.
4. Run the service-port command to create a service port, adopt traffic profile 5, and set the
S-VLAN ID to 50. Set the VDSL channel mode to PTM, and create service port 3 on VDSL
port 0/4/1. To facilitate the maintenance of the service port, also configure the service port
description.
huawei(config)#service-port 3 vlan 50 vdsl mode ptm 0/4/1 inbound traffic-
table
index 5 outbound traffic-table index 5
huawei(config)#service-port desc 3 description Vlanid:50/vdsl/vpi:1vci:39/
stacking
5. Set the C-VLAN ID of the preset service port 3 to 10 for identifying the user. Configure
the important user packet with a higher priority so that the user packet can be processed
with precedence, and set the priority of the inner VLAN to 4.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
3 Configuring the DSLAM Services
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
257
