Huawei SmartAX MA5608T User Manual

Item Data
Multicast program ISP 1
l Program source address: 10.10.10.10
l program1: 224.1.1.1
l program2: 224.1.1.2
l Maximum program bandwidth: 3500 kbit/s
l Program log reporting: enabled
ISP 2
l Program source address: 10.10.10.11
l program3: 224.1.1.3
l program4: 224.1.1.4
l Maximum program bandwidth: 5000 kbit/s
l Program log reporting: enabled
Right profile
Music program
l Profile name: music
l Program right: watch
Video program
l Profile name: movie
l Program right: watch
VDSL port attribute Working mode: PTM
Bound line profile and alarm profile: default profiles (profile
ID: 1)
Port connected to user 1: 0/2/1
Port connected to user 2: 0/4/1
Multicast user User 1:
l Name of the bound right profile: music
l Maximum multicast bandwidth: 10 Mbit/s
l Multicast user log recording: enabled
User 2:
l Name of the bound right profile: movie
l Maximum multicast bandwidth: 5 Mbit/s
l Multicast user log recording: enabled
Procedure
Step 1 Configure multicast VLANs and programs.
Configure smart VLAN 10 as the multicast domain of ISP 1, and smart VLAN 20 as the multicast
domain of ISP 2.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
3 Configuring the DSLAM Services
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
294

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
