Table 1-5 Usage of the DIP switches
Electric
Switch
Usage
S5-1 Used to set the external sensor type of JTA1-JTA4. For detailed information,
see Table 1-6.
l ON: The external sensors are of the current type.
l OFF: The external sensors are of the voltage type.
S5-2
S5-3
S5-4
S6-1 Used to set the sub-node ID. This value must correspond with the configured
ESC sub-node ID in the system and cannot be identical to the address value of
the sub-node. Such restrictions ensure that the H801ESC board can
communicate with the control board. For detailed information, see Table 1-7.
l ON: The mapping address bit is 0.
l OFF: The mapping address bit is 1.
S6-2
S6-3
S6-4
S6-5
S6-6 Reserved.
S6-7
S6-8 Used to set the baud rate of the communication between the H801ESCA board
and the control board.
l ON: The baud rate is 19200 bit/s (default).
l OFF: The baud rate is 9600 bit/s.
Table 1-6 describes the mapping between S5-1 to S5-4 and sensor ports.
Table 1-6 Mapping between S5-1 to S5-4 and sensor ports
Electric Switch OFF ON
S5-1 The external sensor of JTA1 is of the
voltage type.
The external sensor of JTA1
is of the current type.
S5-2 The external sensor of JTA2 is of the
voltage type.
The external sensor of JTA2
is of the current type.
S5-3 The external sensor of JTA3 is of the
voltage type.
The external sensor of JTA3
is of the current type.
S5-4 The external sensor of JTA4 is of the
voltage type.
The external sensor of JTA4
is of the current type.
S6-1 to S6-5 are used to set the sub-node IDs of the H801ESC board. Table 1-7 lists the mapping
between S6-1 to S6-5 and sub-node IDs.
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide
1 Commissioning
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8
