S6-5 S6-4 S6-3 S6-2 S6-1 Address

Value of Sub-

nodes

1 1 0 1 1 11011(27)

1 1 1 0 0 11100(28)

1 1 1 0 1 11101(29)

1 1 1 1 0 11110(30) is

used by the

ESC board, and

the H801ESC

board cannot be

set to this value.

1 1 1 1 1 11111(31)

Procedure

Step 1 Remove the cable connector if the H801ESC board is connected to an environment monitoring

cable.

Step 2 Loosen the screws on the H801ESC board anticlockwise by using the Phillips screwdriver, as

shown in (1) of Figure 1-3.

Figure 1-3 Removing the H801ESC board

Step 3 Hold the ejector lever of the front panel and remove the H801ESC board from the PDU, as shown

in (2) of Figure 1-3.

SmartAX MA5600T/MA5603T/MA5608T Multi-service

Access Module

Commissioning and Configuration Guide

1 Commissioning

Issue 01 (2014-04-30) Huawei Proprietary and Confidential
