Huawei SmartAX MA5608T User Manual

Data Plan
Table 3-19 shows the key data for configuring the triple play in single-PVC for multiple services
mode on the MA5600T/MA5603T/MA5608T.
Table 3-19 Data plan for configuring the triple play in single-PVC for multiple services mode
(user-based and stream-based rate limitation)
Config
uration
Item
Data Remarks
Internet access VoIP IPTV
Upstrea
m port
0/19 0 -
ADSL2
+ port
l User 1: 0/2/0
l User 2: 0/2/1
l ADSL2+ channel profile
– ID: 3
– Minimum upstream/downstream rates: 32 kbit/s
– Minimum reserved upstream/downstream rate: 32 kbit/s
– Maximum upstream rate: 4096 kbit/s
– Maximum downstream rate: 10240 kbit/s
l ADSL2+ line template:
– ID: 3
– Upstream/Downstream rate adaptation ratio of channel:
100
l ADSL2+ line alarm template ID: 1
-
VLAN
l SVLAN ID: 2
l SVLAN type:
smart
l CVLAN ID:
20
l SVLAN ID: 3
l SVLAN type:
smart
l CVLAN ID:
30
l SVLAN ID: 4
l SVLAN type:
smart
l CVLAN ID: 40
-
SmartAX MA5600T/MA5603T/MA5608T Multi-service
Access Module
Commissioning and Configuration Guide 3 Configuring the DSLAM Services
Issue 01 (2014-04-30) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
381

Huawei SmartAX MA5608T Specifications

General

Dual Power Supply	Yes
Humidity	5% to 95% (non-condensing)
Uplink Slots	2
Maximum GPON Ports	16
Input Voltage Range	-38.4 V DC to -72 V DC
Device Type	OLT
Power Supply	-48 V DC
Operating Temperature	-25°C to +55°C
Storage Temperature	-40°C to 70°C
Switching Capacity	128 Gbps
Ports	GPON, XG-PON, 10GE
